Heavy Duty Flexible Gravity Roller Conveyor for warehouse

Name: Heavy Duty Flexible Gravity Roller Conveyor for warehouse
Brand: YiFan
Price: 1 USD

China Heavy Duty Flexible Gravity Roller Conveyor for warehouse wholesale

Brand Name : YiFan

Model Number : FGR

Certification : Flexible Conveyors

Place of Origin : Ningbo,China

MOQ : 1 unit

Price : optional

Payment Terms : T/T,L/C

Supply Ability : 100 units/month

Delivery Time : 2 weeks

Packaging Details : plywood pallet/cardboard/bubble film

Load Capacity : 95kg/m

Material : Carbon steel

Material Feature : Good Load Capacity:95kg

Structure : Roller Conveyor

Type : Gravity Conveyor

Condition : New

Conveyor Width : 400-1000mm

Conveyor Height : 700-1000 or 800-1200mm

Conveyor Length : optional

Roller Materials : plastic or steel

Roller Width : 400-1000mm

Roller Numbers : 9pcs/m

Wheels/Casters : swivel casters,lockable casters

Contact Now

Description

Heavy Duty Flexible Gravity Roller Conveyor for warehouse are designed for versatility.They are exceptional for truck loading and unloading,retail stores,shipping areas,loading docks and plant floors.

Features

Self Tracking-Cartons follow the twists and turns of the conveyor path without using engineered curves.
Detachable Round Tubing Legs-Exclusive heavy-duty round tubing legs for longer service life and reduce packing size.
Adjustable Height-Simply turn the locking knob to raise and lower the conveyor bed height.

Specifications

Gravity Flexible Roller Conveyors applied in loading docks/plant floors/shipping areas

Conveyor Width:400-1000mm

Conveyor Height:700-1000mm or 800-1200mm

Conveyor Length:1m-10m,optiona

Load Capacity:95kg/m

Roller Materials:steel/plastic

Roller Width:400-1000mm

Roller Diameters:38mm,45mm,50mm

Roller Numbers:9pcs/m

Wheels/Casters:swivel casters,lockable casters

Structure:Roller Conveyor

Type:Gravity Conveyor

Condition:New

Model Number:WS

MODEL LIST

Model	Open Length (mm)	Close Length (mm)	Width (mm)	AdjustableHeight (mm)	Max.Load (kg/㎡)
FGR-H4	4800	2040	600,700,800	700-1000	95
FGR-H6	6000	2550	600,700,800	700-1000	95
FGR-H7	7200	3060	600,700,800	700-1000	95
FGR-H8	8400	3570	600,700,800	700-1000	95
FGR-H9	9600	4080	600,700,800	700-1000	95
FGR-H10	10800	4590	600,700,800	700-1000	95
FGR-H12	12000	5100	600,700,800	700-1000	95
FGR-H13	13200	5610	600,700,800	700-1000	95
FGR-H14	14400	6120	600,700,800	700-1000	95
FGR-H15	15600	6630	600,700,800	700-1000	95
FGR-H16	16800	7140	600,700,800	700-1000	95
FGR-H18	18000	7650	600,700,800	700-1000	95
FGR-H19	19200	8160	600,700,800	700-1000	95
FGR-H20	20400	8670	600,700,800	700-1000	95

Heavy Duty Flexible Gravity Roller Conveyor for warehouse

Ningbo YiFan Conveyor Equipment Co.,Ltd.

Email:sales@yfconveyor.com

Web: www.yfconveyor.com

Mob:+86 139 5824 8487

YES, quickly and easily join together by hooks
Can the width be customized?
YES
What is the Min.width do you have?
350mm
What is the Max.width do you have?
YES
Is the height adjustable?
YES, 700-1000mm or 800-1200mm
Can the height be customized?
YES
Do you have stainless steel 304 rollers?
YES
Do you have PVC rollers?
YES
How many KGS can this conveyor carry?
50KGS per square meter
What products can this conveyor be used to load?
Cartons,boxes with FLAT & HARD bottoms
How do you dispatch this conveyor?
Dispatch it completely
How many countries have you sell this conveyor to?
UK,America,France,Canada,Russia,Romania,Chile,Jordan,UAE,Spain,Qatar,Kenya,South Africa,Iran,Pakistan,Vietnam,Philippines,etc.
How long is the delivery time?
10-15 days
How long is the warranty?
1 year
Do you supply OEM & ODM service?
YES
Do you have user’s guide and maintenance instruction?
YES
What are the necessary spare parts we should keep?
wheels,screws
